特点
- 符号率：2 GBd 至 120 GBd
- 支持非归零（NRZ）、PAM4、PAM6 和 PAM8 线路编码
- 内置七个分流器去加重，可以改善通道损耗补偿
- 跳变时间 < 5 ps，均方根（RMS）固有随机抖动 < 100 fs
- 提供经过集成和校准的抖动注入，可用于 RJ、PJ1、PJ2、BUJ、sRJ 和 clk/2 接收机容限测试
- 灵活的解决方案，功能可通过软件许可证升级
目标应用
M8050A 可帮助工程师设计和表征芯片、器件、收发信机模块、子组件、电路板和系统。 它还可快速测试在服务器、计算、数据中心和通信等行业中使用的、数据速率高达 120 GBd 的串行 I/O 端口。 M8050A BERT 与 Keysight UXR 系列 80 GHz 示波器相结合，可以构成一个完整的 1.6T 接收机和发射机测试解决方案，用于对您的以太网系统进行全面评测。
主要技术指标
Meet the 120 GBd High-Performance BERT
Pathfinding for next-gen data standards
Leading-edge developers use high-performance bit error ratio testers to perform BER and receiver testing for a variety of next-generation technologies, including 800G/1.6T Ethernet, USB4v2, PCIe 6.0, and more.
The Custom Power Behind Our Instruments
Pushing the boundaries of technology requires instantaneous bandwidth, spurious-free dynamic range, and signal fidelity beyond basic measurements. Keysight powers every performance product with custom MMICs, designed in-house, manufactured in our proprietary indium phosphide (InP) and gallium arsenide (GaAs) fab with custom ASIC signal processing that ensure the industry’s fastest, most reliable measurements. Count on Keysight to accelerate your next innovation. In our high-performance BERTs and AWGs, Keysight semiconductors enable speed, bandwidth, and flexibility for terabit transmission systems, resulting in excellent eye diagrams.
SD7150A 1.6T Receiver and Transmitter Test Solution
This new solution bundle for characterizing 1.6T receivers and transmitter includes the M8050A pattern generator up to 120 GBd PAM4 and a 80 GHz UXR. For analyzing errors above 58 Gbd, the Infiniium UXR realtime oscilloscope can be controlled by the M8000 system software. The UXR can be used for measuring the transmitter output performance as well as acquisition hardware for error analysis when controlled by M8070B.
- BER measurements up to 120GBd with long PRBS31Q, QPRBS13, etc.
- Digital equalization and flexible clock recovery settings
- Supports NRZ, PAM4, PAM6, PAM8
- Superior input sensitivity and low noise
.png)
.png)
Interested in a M8050A?
Innovate at Speed with KeysightCare Curated Support Plans
As digital and RF test complexity increases, optimize project schedules and mitigate risks while ensuring the quality of your end-products with KeysightCare.
The instruments featured on this page include one year of KeysightCare Assured with the option to upgrade.
- Maximize uptime and reduce delays caused by equipment downtime or malfunction with prioritized, contracted turn-around times for unlimited repairs.
- Increase measurement predictability with prioritized turn-around times for your Keysight Certified calibration of choice.
- Solve problems and optimize tests and measurements more quickly with our fastest, prioritized response times from experts who can help you resolve issues when they arise.
- Reduce costs and minimize unplanned budget events with multi-year plans to lock in the lowest prices and no hidden or add-on costs.
